Counter UAV Drone Professional GNSS Spoofer | Anti-Drone GNSS Spoofing & Navigation Satellite Deception Equipment for Defense Systems
| Lugar de origem | SHENZHEN |
|---|---|
| Marca | Ladasky |
| Número do modelo | LDSK-AY06/LDSK-AY13/LDSK-AY22 |
| Quantidade de ordem mínima | 1 |
| Preço | $7858-$25000 |
| Tempo de entrega | 5-8 dias |
| Termos de pagamento | L/C,D/A,T/T,D/P,Western Union,MoneyGram |
| Habilidade da fonte | 5000 unidades/mês |
Contacte-me para obter amostras grátis e cupões.
Whatsapp:0086 18588475571
Conversamos: 0086 18588475571
Skype: sales10@aixton.com
Se tiver alguma preocupação, fornecemos ajuda online 24 horas por dia.
xDetalhes do produto
| Faixa | 5km-20km personalizáveis | Métodos de falsificação | orientação de rumo, dissuasão, pouso forçado e colisão rápida. |
|---|---|---|---|
| Sinais de navegação | GPS, BDS, GLONASS, Galileo, QZSS e IRNSS （Personalizável） | Dimensões | 430*370*175mm (sem antena) |
| Tensão de alimentação externa | CA 110-300 V | ||
| Destacar | Portable drone detector with GNSS spoofer,Anti-drone GNSS spoofing equipment,Navigation satellite deception defense system |
||
Descrição de produto
Counter UAV Drone Professional GNSS Spoofer
Anti-Drone GNSS Spoofing & Navigation Satellite Deception Equipment for Defense Systems
Navigation Satellite Deception Equipment
This professional counter-drone equipment is specifically designed for security applications in oil and petrochemical facilities, power plants, public security operations, and military installations. Featuring a compact, lightweight design with reliable performance and user-friendly operation, it enables rapid deployment and integration. Utilizing advanced navigation satellite signal simulation technology, the system broadcasts simulated satellite signals identical to operational navigation satellites. When drones receive these signals, they use them for positioning, allowing the system to implement multiple deception strategies including heading guidance, deterrence, forced landing, and rapid crash protocols.
Product Features
- Supports signal reception and simulated transmission from all four major global navigation satellite systems, plus commonly used frequencies in Japan and India
- Performs navigation deception on UAVs relying on satellite navigation, achieving objectives including forced landing, heading guidance, takeoff prohibition, and signal interference
- Compatible with external direction finding modules for target azimuth identification and horizontal movement control (forward, backward, left, right)
- Supports external command control for arbitrary navigation signal combination transmission
- Configurable position coordinates (longitude, latitude, altitude) via external commands or built-in fixed coordinates
- Adjustable simulation parameters including signal delay, motion speed, and acceleration via external commands
- Supports preset trajectories such as linear motion and circular motion via external commands
- Accepts externally added motion trajectories; calculates and outputs corresponding navigation satellite signals
- Operates in both real-time ephemeris mode and permanent ephemeris mode
- Provides satellite navigation signal suppression and interference output capabilities
- Includes network secondary development control interface for system integration
Technical Specifications
Performance Parameters
| Item | Specification |
|---|---|
| Deception Distance | Customizable according to customer requirements |
| Supported GNSS Systems | GPS, BDS, GLONASS, Galileo |
| Receiving Frequencies | BDS-B1, GPS-L1 / L2 / L5, GLONASS-L1, Galileo-E1 |
| Attenuation Adjustment Range | 80 dB |
| Attenuation Resolution | 1 dB |
| Power-on Startup Time | 60 s |
| GNSS Signal Synchronization Time | < 180 s |
GNSS Signal Simulation Capability
| No. | Satellite System | Frequency Band | Channels |
|---|---|---|---|
| 1 | BDS | B1I | 16 |
| 2 | GPS | L1 C/A | 16 |
| 3 | GPS | L2 | 16 |
| 4 | GPS | L5 | 16 |
| 5 | GLONASS | L1 | 16 |
| 6 | Galileo | E1 | 16 |
Distance vs Output Power Reference
| Deception Distance | Output Power |
|---|---|
| 5 km | 5 W |
| 10 km | 20 W |
| 20 km | 50 W |
Frequently Asked Questions
Q1: Are you a factory or trading company?
We are a factory located in Shenzhen City, China. Welcome to visit us.
Q2: Why Choose Us?
- Excellent Products: Effective, Popular, Affordable
- Fast Delivery: Priority Production for Urgent/Bulk Orders
- After-Sales Service: Free Replacement for Faulty Products
Q3: What can you buy from us?
- Jamming/Detection Module
- Drone Jammer
- Drone Detector
- Integrated detection and jamming device
Q4: What is the process of placing an order?
Communication → Payment → Production → Shipment
Q5: How about the shipping time and shipping method?
Typically 5-10 business days (depending on the product). We support almost any shipping method you require.
Q6: How to contact us?
Please leave your email address/WhatsApp number, and we will contact you.
Ordering Process
- Send us products you're interested in
- We provide detailed information and quotations
- Consult with us about any product questions
- Confirm order and receive payment information
- We send package confirmation and tracking number
- Provide feedback after receiving goods
